Specifications displayed may vary based on manufacturer year, model change and tire size. If you require certain specifications please contact an HR2 representative.
Platform Height
65'
Horizontal Outreach
56' 2"
Lift Capacity
500 lbs
Platform Rotator
160°
Platform Size
3' x 8'
Overall Width
8' 2"
Tailswing
4'
Stowed Height
8' 11"
Stowed Length
30' 11"
Wheelbase
8' 3"
Ground Clearance
1' 2.5"
Weight
22,100 lbs (2WD) 22,270 lbs (4WD)
Drive Speed 2WD 4WD
3 mph (stowed)
Gradeability 2WD 4WD
30% (2WD) 45% (4WD)
Turning Radius 2WD 4WD (Inside)
7' 9"
Turning Radius 2WD/4WD (Outside)
18' 2"
Power Source
Fuel
Fuel Type
35 gal
Fuel Capacity
12V DC
Auxiliary Power
12V
Noise Level
65'
Web SKU
650G
